FMS-Q 350 RS
High-performance automatic punching and bending machine with 350 kN punching force.
The FMS-Q 350 RS combines high punching force with smooth, precise production. Strip up to 60 mm wide (special: 120 mm) and 3.0 mm thick, up to 250 parts per minute. Ideal for medium-gauge components in the automotive and electronics industries.
Specifications at a glance
Relevant technical data, detailed configuration options and accessories can be found below or in the data sheet.
- Production rate
- 25 – 250 parts/min
- Strip width
- up to 60 mm
- Material thickness
- up to 3 mm
- Wire diameter
- up to Ø 8 mm
- Feed
- Mechanical gripper feed or servo feed
- Punching force
- 350 kN
- Punching stroke options
- 18 mm
- Punching units
- up to 1
- Bending slides
- up to 11
- Biegekraft
- 40 – 60 kN
- Bending stroke
- 65 mm
- Drive power
- 22 kW
- Tool change
- 30 min.
- Dimensions (L × W × H)
- 2700 × 1600 × 2300 mm
- Weight
- 8500 kg
- Control system
- B&R control system with Powerlink interface, IPC with touchscreen and tool monitoring
- Colors (base / covers)
- RAL 7035 / RAL 5003
Applications of the FMS-Q 350 RS
-
Automotive industry
Spring elements, contact bridges, fastening clips and connector components for wiring systems, body and electronics. High volumes, consistent precision.
-
Construction industry
Fastening and connecting parts for drywall construction, prefabricated modules, façade systems and structural applications — galvanized or in stainless steel.
-
Energy technology
Busbars, contact terminals and high-current connections made of solid copper and brass for switchgear, photovoltaics and power distribution.
-
Plant engineering
Load beams, brackets, suspensions and structural parts with high material thickness for industrial plants, process engineering and mechanical engineering.
-
Electrical industry
Stamped and formed parts for switches, relays, connectors, fuses and PCB holders — gold- or tin-plated, highest dimensional accuracy.
-
Konsumgüterindustrie
Federn, Kontakte, Clips und Drahtkörbe für Haushaltsgeräte, Möbel und Accessoires. In Millionen-Serien wirtschaftlich und prozesssicher gefertigt.
-
Medical technology
Stainless steel lamellae, surgical instrument components and precision micro parts with mirror polish — biocompatible and certifiable.
-
Furniture industry
Fittings, drawer slides, hinges and decorative connecting parts in chrome or galvanized finish — precise and highly repeatable.
-
Special-purpose machinery
Large-volume parts with long cycles and multiple bending operations. Ideal for asymmetric, wide-format and project-specific workpieces.
Compatible components & options
Strip straighteners
- SSU-RL 50 50 mm bandwidth
Wire straighteners
- WSU-RL 3,5 Wire 1.5–3.5 mm
- WSU-RL 6,0 Wire 2.0–6.0 mm
Mechanical feeds
- MFU-R 250/110 Stroke length 250/110 mm
- MFU-R 300/110 Stroke length 300/110 mm
Press modules
- PM 350/18 350 kN, 18 mm Hub
Bending slides
- FU 40/65 40 kN, 65 mm Hub
- FU 60/55 60 kN, 55 mm Hub
